MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
C_Ref
Connection reference
Slot
Used in the slave for addressing of the desired data block. Range 0...254.
Index
Used in the slave for addressing of the desired data block. Range 0...254.
Length
Number of bytes to write.
Error Decode, Error Code 1 & 2
If 'Fault Information' equals 0010h, additional information according to the DPV1
specification can be found here.
Extended Fault Information
If 'Fault Information' equals 000Ah or 000Bh, additional information of the error
can be found here.
Fault Information
If 'Invalid Other' is returned in the Message Information word in the header of the
response, information about the fault can be found here.
"Fault Information"
000Ah
Failed to execute request (local
error detected)
000Bh Remote station failure
0010h Remote station DPV1 failure
00FFh Module offline (not initialized or no
valid database)
Write Data
Data written from the Master to the slave using the Write command.
ProSoft Technology, Inc.
July 8, 2011
"Extended Fault Information" Contents
See Extended Fault Information.
-
Mailbox Messaging
