Reference
User Manual
60 Words Output Data Block Format (Output Image)
Word Offset
Start
End
0
0
1
50
51
51
52
52
53
53
54
55
56
57
58
60
Page 170 of 225
Name
Description
Block ID
Block number 1 to 16
Output Data
PROFIBUS Output Data (50 words of data)
Last Out Mailbox ID Last out mailbox message ID sent through output
Last In Mailbox ID
Last in mailbox message ID processed from input
Last Alarm ID
Last alarm message ID processed from input image
PROFIBUS CRC
PROFIBUS CRC32 value
Module CRC
Module CRC32 value
Reserved
Reserved for future use
MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
ProSoft Technology, Inc.
July 8, 2011
