Module Setup
User Manual
To use the CIPconnect Path Editor
1 Click CIP P
Parameter
Source Module
Source Module IP Address
Source Module Node Address
Destination Module
Destination Module Slot Number
2 Click C
ONSTRUCT
3 Click OK to confirm the configured path.
The following example should provide a better understanding on how to set up
the path for your network.
Page 74 of 225
E to open the CIPconnect Path Editor dialog box.
ATH DIT
Description
Source module type
IP address of the source module
ControlNet Node address of the source module
Note: Not currently used by MVI69 modules
Select the destination module associated to the source module
in the rack. The connection between the source and destination
modules is performed through the backplane.
The slot number where the destination module is located
CIP P to build the path in text format
ATH
