MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
Command and Response Layout: Set Slave Mode
Message ID
Message information
Command
Data size
Frame count
Frame number
Offset high
Offset low
Extended word 1
Extended word 2
Extended word 3
Extended word 4
Extended word 5
Extended word 6
Extended word 7
Extended word 8
Message Information
Refer to Message Information (page 128).
Slave Address
Range 1 to 125; 127
If the request applies for only one slave, that slave address must be entered in
the range 1 to 125. If a slave group is to be addressed, slave address should be
127 (multicast address).
ProSoft Technology, Inc.
July 8, 2011
Command
(ID)
4002h
0003h
0000h
0001h
0001h
0000h
0000h
Slave Group Select
Address
Control
Command
-
-
-
-
-
Response
(ID)
0002h
0003h Set Slave Mode
0000h
0001h
0001h
0000h
0000h
Slave Group Select
Address
Control
Command
-
-
-
-
Extended Fault Information
Fault Information
Mailbox Messaging
