Reference
User Manual
120 Words Block Format for Mailbox In Message (Input Image)
When the Block Transfer Size = 120, it takes two Output blocks to form one
complete mailbox message request. Each Output block will be responded to with
a corresponding Input block with the same ID number.
Note: Since the same two Output Block IDs are always used for 120-word block format requests,
the Input Block IDs will always be the same two numbers, as well, 100 and 101.
Word Offset
Start End
0 0
1 1
2 121
Word Offset
Start End
0 0
1 1
2 25
26 121
Page 182 of 225
Name Description
Block ID Block number 100
Output Index Index of Output image to receive (1 to 8 for data, 0 or
-1 if no data)
Mailbox Message Mailbox input message from module (first 120 words
of mailbox message)
Name Description
Block ID Block number 101
Index of Output image to receive (1 to 8 for data, 0 or
Output Index
-1 if no data)
Mailbox Message Mailbox input message from module (last 24 words of
mailbox message)
Reserved Reserved for future use
