Mailbox Messaging
User Manual
D_Type
This parameter indicates the presence of the optional Network/MAC address of
the destination.
bit 0:
D_Address.
endpoint of
bits 1 through 7:
Default value is 00h.
D_Length
This value specifies the length of the D_Address parameter (see table below).
Default value is 02h.
S_Address
This field holds additional address information about the source. It's structure
depends on the settings in S_Type.
S_Type Type
Unsigned8
00h
Unsigned8
Unsigned8
Unsigned8
Octet-string[6] Network Address
01h
Octet-string
[S_Length - 8]
Page 114 of 225
MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
1 = A Network/MAC address is present in
0 = The destination (in this case the module) is the
the connection.
(reserved for future use)
Sub–parameter Description
Identifies the application process
API
instance of the source.
Identifies the access level of the
SCL
source (0 = not used)
Identifies the application process
API
instance of the source.
Identifies the access level of the
SCL
source.
Identifies the network address of
the source according to ISO/ OSI-
Network addresses.
Identifies the MAC address of the
MAC Address
source
PROFIBUS DPV1 Master
