MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
D_Address
This field holds additional address information about the destination. It's structure
depends on the settings in D_Type.
D_Type Type
Unsigned8
00h
Unsigned8
Unsigned8
Unsigned8
Octet-string[6]
01h
Octet-string
[D_Length - 8]
ProSoft Technology, Inc.
July 8, 2011
Sub–parameter Description
Identifies the application process
API
instance of the destination.
Identifies the access level of the
SCL
destination. (0 = not used)
Identifies the application process
API
instance of the destination.
Identifies the access level of the
SCL
destination.
Identifies the network address of
Network Address the destination according to
ISO/OSI-Network addresses.
Identifies the MAC address of the
MAC Address
destination
Mailbox Messaging
