MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
1.2

Package Contents

The following components are included with your MVI69-PDPMV1 module, and
are all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty. Part Name
1 MVI69-PDPMV1
Module
1 Cable
1 Cable
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
ProSoft Technology, Inc.
July 8, 2011
Part Number Part Description
MVI69-PDPMV1 PROFIBUS DPV1 Master
Cable #15, RS232 For RS232 Connection to the CFG Port
Null Modem
Cable #14, RJ45 to For DB9 Connection to Module's Port
DB9 Male Adapter
cable
Start Here
User Manual
