4.4.15 Mailbox Message: Class 2 Connection Abort Indication

This message is issued spontaneously by the module when any of the
established connections has been aborted for reasons not caused by the
application (e.g. slave time-out, connection terminated by slave etc.). This
message is not issued when a connection has been terminated using
FB_APPL_MSAC2_ABORT .
Note: The application must not respond to this message!
Note:This feature can be disabled, see "Fieldbus Specific Initialisation (FB_INIT)"
Parameter
Command Initiator
Command Name
Command Number
Fragmented
Message Layout:
Message ID
Message information
Command
Data size
Frame count
Frame number
Offset high
Offset low
Extended word 1
Extended word 2
Extended word 3
Extended word 4
Extended word 5
Extended word 6
Extended word 7
Extended word 8
C_REF
Connection reference number used to identify the connection.
Range: 1 to 128
Page 122 of 225
Description
Module
FB_APPL_MSAC2_ABORT_IND
002Ah
No
Command
(ID)
4002h
002Ah FB_APPL_MSAC2_ABORT_IND
0000h
0001h
0001h
0000h
0000h
C_REF
Subnet Reason
Code
Additional Detail
Locally Generated
-
-
-
-
