5.3.2 PROFIBUS Master Indicators

LED State
TKN HLD GREEN
OFF
DBASE STAT GREEN
GREEN-Flashing
RED
OFF
MSTR STAT GREEN
GREEN-Flashing
RED
OFF
COM STAT GREEN
GREEN-Flashing
RED
OFF
ALL LEDs RED
ProSoft Technology, Inc.
July 8, 2011
Description
The module has the token
The module does not have the token
Database OK
Database download in progress
Invalid database
No databases have been downloaded
Operating mode
Clear mode
Stop mode
Offline
Data exchange with all configured slaves
Data exchange with at least one configured slave but not all configured slaves
Bus control error (possible bus short circuit or configuration error)
No data exchange with any configured slave
Fatal error
