Mailbox Messaging
User Manual
Group Select
Range 01h to FFh (Bit Coded)
This parameter determines which group to address. Refer to the following
example:
b7 b6
Group 8 Group 7
Example:
To address Group 1, 2, and 4, the Group Select value should be D0h. If an
individual slave should be addressed, the correct group selection must also be
made, because the slave will ignore the message if it does not belong to the
requested group(s).
What group(s) a slave belongs to is determined during network configuration,
and is downloaded during initialization to each slave via the PROFIBUS telegram
Set_Prm.
Control Command
This parameter specifies the command to send:
Bit
0 (LSB)
1
2
3
4
5
6
7 (MSB)
Combinations of the bits (Unsync/Sync and Unfreeze/Freeze)
Bits 0 or 6
0
0
1
1
Page 92 of 225
b5 b4
Group 6 Group 5
Explanation
Reserved, set to zero
Reserved, set to zero
Unfreeze input data
Freeze input data
Unsynchronize output data
Synchronize output data
Reserved, set to zero
Reserved, set to zero
Bits 1 or 7 Explanation
0 No function
1 Function will be activated
0 Function will be inactive
1 Function will be inactive
MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
b3 b2 b1
Group 4 Group 3 Group 2
PROFIBUS DPV1 Master
b0
Group 1
