120 Words Input Data Block Format (Input Image)
Word Offset
Start End
0 0
1 1
2 101
102 102
103 103
104 104
105 105
106 107
108 109
110 121
60 Words Input Data Block Format (Input Image)
Word Offset
Start End
0 0
1 1
2 51
52 52
53 53
54 54
55 55
56 57
58 59
60 61
Page 168 of 225
Name Description
Block ID Block number 1 to 8
Output Index Index of Output image to receive (1 to 8 for data, 0 or
-1 if no data)
Input Data PROFIBUS Input Data (100 words)
Last Out Mailbox ID Last out mailbox message ID processed from output
Last In Mailbox ID Last in mailbox message ID sent in input image
Last Alarm ID Last alarm message ID sent in input image
Reserved Reserved for future use
PROFIBUS CRC PROFIBUS CRC32 value
Module CRC Module CRC32 value
Reserved Reserved for future use
Name Description
Block ID Block number 1 to 16
Output Index Index of Output image to receive (1 to 16 for data, 0
or -1 if no data)
Input Data PROFIBUS Input Data (50 words)
Last Out Mailbox ID Last out mailbox message ID processed from output
Last In Mailbox ID Last in mailbox message ID sent in input image
Last Alarm ID Last alarm message ID sent in input image
Reserved Reserved for future use
PROFIBUS CRC PROFIBUS CRC32 value
Module CRC Module CRC32 value
Reserved Reserved for future use
