MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
5.6

Standard PROFIBUS Slave Diagnostic Bytes

The diagnostic information consists of 6 bytes of standard diagnostic information
plus any user-related diagnostic information. The standard information is shown
in the tables below.
Byte
0
1
2
3
4
5

5.6.1 Byte 0 - Station Status 1 Bits

Bit
0
1
2
3
4
5
6
7

5.6.2 Byte 1 - Station Status 2 Bits

Bit
0
1
2
3
4
5
6
7
ProSoft Technology, Inc.
July 8, 2011
Description
Station status 1
Station status 2
Station status 3
Master address
Ident number high
Ident number low
Description
Station not existent
Station not ready
Configuration fault
Extended diagnostic data present
Not supported
Invalid slave response
Parameter fault
Master lock
Description
Parameter request
Static diagnostic
Slave device
Watchdog on
Freeze mode
Sync mode
Reserved
Slave deactivated
Diagnostics and Troubleshooting
