5.1.2 Viewing the Online Status of the PROFIBUS Network

Note: For this procedure, you must connect a serial cable from the serial port on your PC to the
RJ45 to DB9M adaptor cable on the MVI69-PDPMV1 module.
1 In ProSoft Configuration Builder for PROFIBUS, open the O
then choose M
communication with the MVI69-PDPMV1 module, and will indicate
communication status.
If the slave icon in the Bus Configuration window has a green border, then
o
the MVI69-PDPMV1 module is correctly communicating with the
PROFIBUS slave.
If the slave icon in the Bus Configuration window has a red border, then
o
the module is not communicating with the slave.
If the slave icon in the Bus Configuration window has a blue border, the
o
slave is communicating with the Master, but is generating diagnostic data.
To view diagnostic data for the slave, select the slave, and click the right
mouse button to open a shortcut menu. On the shortcut menu, choose
O
NLINE
ProSoft Technology, Inc.
July 8, 2011
/M . ProSoft Configuration Builder will establish
ONITOR ODIFY
P .
ROPERTIES
