Ladder Logic
User Manual
2
Select 1769-MODULE.
3
Set the Module Properties values as follows:
Parameter
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance
Configuration Size
Page 22 of 225
MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
Value
Enter a module identification string. Example:
MVI69PDPMV1
Enter a description for the module. Example: PROFIBUS
DPV1 M
ASTER
Select D
-INT
ATA
Enter the slot number in the rack where the MVI69-
PDPMV1 module will be installed.
101
62 / 122 / 242
100
61 / 121 / 241
102
0
PROFIBUS DPV1 Master
ProSoft Technology, Inc.
July 8, 2011
