MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
Word Offset
Start End
44 44
45 46
47 48
49 60
Word Offset
Start End
0 0
1
2
3
4
5
6
7
ProSoft Technology, Inc.
July 8, 2011
Name Description
PROFIBUS Master Represents the PROFIBUS Master module's
Module Status operating status.
Bit 2=Application Status
0 - Application Stopped
1 - Application Running
Bit 8=data exchange (FBRS)
0 - There is no data exchange with any of the
assigned slaves
1 - There is Data Exchange with at least one of the
assigned slaves
Bit 9=slave input frozen/cleared (FBFC)
0 - A slaves inputs in the IN area are cleared in a
slave is not in Data Exchange
1 - A slave's inputs in the IN area are frozen if a
slave is not in Data Exchange
Bit 12=reset (RDR)
0 - No action
1 - A reset is requested by the PROFIBUS Master
module because a new database has been
downloaded
PROFIBUS CRC32 checksum for PROFIBUS Master
configuration configuration downloaded from configuration utility
Checksum
MVI69 Module MVI69-PDPMV1 module configuration checksum for
configuration module configuration downloaded from configuration
checksum utility
Reserved for future use
Name Description
Block Index Block index of 0 for second status block
Output Data Index Index of Output image to receive (1 to 16 for data, 0
or -1 if no data)
Application MVI69-PDPMV1 module program scan counter. Can
program scan be used to gauge application code scan time
counter performance
Module PROFIBUS Counter representing the number of times the output
output image data data image is transferred to the module's internal
update counter Master.
Module PROFIBUS Counter representing the number of times the input
input image data data image is transferred from the module's internal
update counter Master.
Module out mailbox Module out mailbox counter
counter
Module in mailbox Module in mailbox counter
counter
Module alarm IND Number of spontaneous alarm messages received
receive counter from slave
Reference
