Module Setup

In This Chapter

Connecting Your PC to the Module ....................................................... 46

Configuring the Module ......................................................................... 47

Backing Up the Project .......................................................................... 68

Downloading the Project to the Module Using a Serial COM Port ......... 70

Downloading the Project to the Module Using CIPconnect ................... 73
This section contains the setup procedure, data, and ladder logic for successful
application of the MVI69-PDPMV1 module. Each step in the setup procedure is
defined in order to simplify the use of the module.
Important: Before connecting the cables, please insert the supplied PROFIBUS adaptor in the
PROFIBUS port on the MVI69 module. This adaptor provides additional space between the front of
the module and the shell of the PROFIBUS cable, allowing the PROFIBUS cable to connect
without interfering with cables connected to the Configuration/Debug port on the module. Refer to
the following illustration for the correct cabling configuration.
