MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
Block Transfer Size = 120
Field
Type
Parent
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance
Configuration Size
Block Transfer Size = 240
Field
Type
Parent
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance
Configuration Size
ProSoft Technology, Inc.
July 8, 2011
Recommended Value
1769-MODULE Generic 1769 Module
Local
MVI69
MVI69 Application Module
Data - INT
The slot number in the rack where the module is installed
101
122
100
121
102
0
Recommended Value
1769-MODULE Generic 1769 Module
Local
MVI69
MVI69 Application Module
Data - INT
The slot number in the rack where the module is installed
101
242
100
241
102
0
Ladder Logic
