MVI69-PDPMV1 ♦ CompactLogix or MicroLogix Platform
PROFIBUS DPV1 Master
1

Start Here

In This Chapter

System Requirements ........................................................................... 12

Package Contents ................................................................................. 13

Installing ProSoft Configuration Builder Software .................................. 14

Setting Jumpers .................................................................................... 15

Installing the Module ............................................................................. 16
To get the most benefit from this User Manual, you should have the following
skills:

Rockwell Automation
ladder logic, and transfer the ladder logic to the processor

Microsoft Windows: install and launch programs, execute menu commands,
navigate dialog boxes, and enter data

Hardware installation and wiring: install the module, and safely connect
PROFIBUS DPV1 and CompactLogix or MicroLogix devices to a power
source and to the MVI69-PDPMV1 module's application port(s)
ProSoft Technology, Inc.
July 8, 2011
®
RSLogix™ software: launch the program, configure
Start Here
User Manual
Page 11 of 225
