5.6.3 Byte 2 - Station Status 3 Bits

Bit
0
1
2
3
4
5
6
7

5.6.4 Byte 3 - Master Address

This byte shows the address of the assigned PROFIBUS Master after
parameterization. If there is an error during the parameterization process, this
byte will display the value FF (hexadecimal).

5.6.5 Byte 4 - Ident Number High

This byte shows the high byte of the specific Ident Number assigned to the
module by the PROFIBUS User Organization.

5.6.6 Byte 5 - Ident Number Low

This byte shows the low byte of the specific Ident Number assigned to the
module by the PROFIBUS User Organization.
Page 156 of 225
Description
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Extended diagnostic overflow
