PDPM ♦ ProLinx Gateway
PROFIBUS DP Master

5.3.1 General Status

Database Address
10400
10401
10402
10403
10404
10405
10406
10407
10408
10409
...
...
10499

5.3.2 Command Status

Command list errors are located in registers 10500 through 10699.

5.3.3 Standard PROFIBUS Slave Diagnostic Bytes

The diagnostic information consists of 6 bytes of standard diagnostic information
plus any user-related diagnostic information. The standard information is shown
in the tables below.
Byte
0
1
2
3
4
5

5.3.4 Byte 0 - Station Status 1 Bits

ProSoft Technology, Inc.
June 24, 2013
Offset Description
0 State
Code
-1 Master not in run or ready mode (restarting)
0 Waiting for initialization
1 Initialized and ready to run or running
1 Mailbox State
2 Scan Counter
3 Mailbox Data Move Counter
4 Mailbox Messages Received Counter
5 Mailbox Message Error Count
6 Global Command Counter
7 Slave Diagnostic Request Counter
8 Slave Counter Request Counter
9 No Valid Data
Description
Station status 1
Station status 2
Station status 3
Master address
Ident number high
Ident number low
Definition
Diagnostics and Troubleshooting
Protocol Manual
Page 49 of 70
