"Transpose ..." options move two channels between the stereo part of the matrix and channels 1
and 2 of the multi-channel part.
"Upmix ..." and "Downmix ..." options mix, copy, and/or apply gains to input channels, to obtain output
channels. Generally, upmixing is a process that creates a bigger channel count at output from a smaller
channel count at input (for example, multi-channel from stereo), and downmixing is the opposite (stereo from
multi-channel).
"Split ..." options create a mono sum from a stereo input, apply the specified attenuation, and send it
to either Left or Right output channel as indicated in the name of the option, while sending no signal to
the other.
"Combine ..." options are special in that they take input from two input streams (designated A and B)
and output to one stream. The routing is indicated in the name of the option, Combine A, B, where the
"side" identified with the A field results as the Left side of the output and B field in the Right side . For
example "Combine Right,Left" takes the stereo Right side from the A stream input into the Left side of the
output channel, and Stereo Left side from the B stream input to the Right side of output.

Output

:
The output of the matrix will result into a network source. You can define this source to be a Livewire
source type or one of the many AES67 options.
Source name is used to identify the source in the network. Livewire sources are advertised and this
name is used in the information propagation. AES67 does not define a required method for how sources
are advertised. Once this is defined, this name may be utilized.
Address is used to define the Livewire channel number or an AES67 address.
Stream type defines the type of stream to be generated from the matrix output. Similar to the input type
field, there are many options available because of AES67 and the type used in Livewire are identified.
`
Packet time defines the latency and bandwidth consumption of the stream. Livewire has historically
given this field a user friendly name such as Live or Standard stereo. The time value is the amount of
