steps:
In the Src Name box, enter the name of the source you'll be assigning to the input.
•
•
In the Channel box, enter the unique Livewire channel number of your audio source.
•
In Stream Type will normally be set to "From Source", meaning that the source itself (a mic,
CD player, etc.) will be providing the audio. However, you can select "To Source" to use the
source's automatically generated Backfeed (mix-minus audio) as in input.
Example: Selecting "From Source" when a phone hybrid is assigned as a VMix Sub input would
use the caller audio; selecting "To Source" would instead use the Mix Minus sent to the hybrid.
•
Select the Enable box next to the input to turn the Submixer input on.
•
Leave the Fade Time boxes set at their default.
The Fade Time function won't be used in normal operation, but can be used to create cross fades
between sources when Pathfinder is dynamically making changes to the VMix.
If, say, 1.0 is entered in the first box, the submixer channel's audio will rise from -∞ to the Gain
value set in the next field in 1.0 seconds. If the field is set to 0, the audio will simply turn on at the
gain value specified.
The second box works the same way, but controls the ON to OFF fade time.
•
In the Gain box, enter the setting, in dB, that you want for the Submixer input. Each input
has its own individual Gain setting.
That's all you need to do to configure a VMix Submixer input stream. You can configure up to 5
input streams per VMix Submixer.
At the bottom of each of the submix sections is an Apply button. Any changes you make will be saved
when this button is pressed. Be sure to save the changes for each submixer as they are configured.
VMIx Submixer Advanced Options
There are some additional options provided for advanced users.
In most cases only the Submix output itself needs a unique channel number, but if you so desire,
each VMix input can also be sent back to the network as a unique source, post the ON/OFF and gain
stage of the VMix. Some users find this useful for constructing "cascaded" mix channels to suit unique
situations. To do so, enter values for these controls:
•
Out Name: The name you give the post-on/off submix channel to send back to the Axia network.
•
Channel: the channel number you assign to the post-on/off submix channel to send back to
the Axia net- work.
Out Stream Type. Choose from Live Stereo, Standard Stereo to enable the direct output
•
