QuiCk-stArt instAllAtion Guide
AxiA Fusion AoiP Console
tHAnk you For PurCHAsinG tHe AxiA Fusion Console.
We have made Fusion the easiest Axia console, ever, to set up. This quick start guide will take you through the
basic steps to configure your new Fusion and have you up and running in no time. Before we get started, let's
check your installation type and make sure you have what you need.
Installation type:
You've got your choice of two mixing engines to pair with the Fusion, the
PowerStation.
the
We are providing instructions for both setups, so make sure you follow the instructions
for your engine
type.
REQUIRED EQUIPMENT, CABLES, AND ACCESSORIES:
There are a few additional items required for a successful installation. Check the list below and make sure
you have what you need.
Included items:
• Fusion Console
• Fusion Power Cable
• CAT5 Ethernet Cable
Items you need to supply:
• Either a StudioEngine mixing engine and separate
Axia Power Supply, or PowerStation mixing engine
(with their appropriate power supply cables)
• 1080p Monitor with DVI Connector
• USB Keyboard (for PowerStation setup only)
• PC with network access
• Configured Network Switch
StudioEngine
or
Advertisement
Table of Contents
Related Manuals for Axia FUSION
Summary of Contents for Axia FUSION
- Page 1 For PurCHAsinG tHe AxiA Fusion Console. We have made Fusion the easiest Axia console, ever, to set up. This quick start guide will take you through the basic steps to configure your new Fusion and have you up and running in no time. Before we get started, let’s check your installation type and make sure you have what you need.
- Page 2 AxiA studioenGine PHysiCAl ConneCtions witH AxiA studioenGine 1. Tilt the overbridge panel of the Fusion Console (A) forward (toward faders) to gain access to the Fusion Console overbridge board. 2. Connect one end of the supplied Fusion power cable to the power port on the Fusion Console overbridge board (B).
- Page 3 5. Select check mark to right of address and tap knob (I) to accept. 6. Repeat for Netmask and Gateway as needed. 7. Select Console (L) and change the option to Fusion. 8. Select OK and tap knob to respond affirmative in order to reboot engine with new settings.
- Page 4 AxiA PowerstAtion PHysiCAl ConneCtions witH AxiA PowerstAtion 1. Tilt the overbridge panel of the Fusion Console (A) forward (toward faders) to gain access to the Fusion Console overbridge board. 2. Connect one end of the 6-Pin molex power cable supplied with the PowerStation to the Surface port (B) on the PowerStation.
- Page 5 HelP If you have more questions, you can access the full manual online at http:/ /www.telosalliance.com/Axia/Fusion or call the Telos Alliance 24/7 Support Team at +1 (216) 622-0247, we’d be happy to help you out. © 2015 TLS Corp., All Rights Reserved.
- Page 6 When prompted for authentication enter user name “user”, password is left blank. 2. The Fusion control center will launch (A). In the left column, under “Mix Engine”, select the “Network” link (B), click the “Install” button at the bottom of the new page.
- Page 7 ConFiGurAtion 1. In the Fusion Control Center, in the left column under “Console”, select “Sources” (A). 2. Click the “Create New Source Profile” button (B). 3. On the Source Profile screen, select “Source Type” from the drop down list (C).
- Page 8 21. Repeat “Source Configuration” steps to configure additional sources. your setuP is ComPlete! That’s it! You are now ready to experience the Axia Fusion, a powerful, flexible and easy to use console, packed with all of the capabilities and features you need. Enjoy!
