Direction 5370626-100, Revision 18
3-1-3
Installation Warnings
1.) There are no operator serviceable components. To prevent shock, do not remove any covers or
panels. Should problems or malfunctions occur, unplug the power cord. Only qualified service
personnel should carry out servicing.
NOTE:
For information regarding packing labels, refer to LABELS ON PACKAGE.
2.) After being transported, the unit may be very cold or hot. If this is the case, allow the unit to
acclimate before you turn it on. It requires one hour for each 2.5×C increment it's temperature is
below 10×C or above 40×C.
Equipment damage possibility. Turning the system on without acclimation after arriving at site
DANGER
may cause the system to be damaged.
Table 3-3
°C
60
55
50
45
°F
140
131
122
113
8
6
4
hrs
3-1-4
Safety Reminders
WHEN USING ANY TEST INSTRUMENT THAT IS CAPABLE OF OPENING THE
DANGER
AC GROUND LINE (I.E., METER'S GROUND SWITCH IS OPEN), DON'T TOUCH
THE UNIT!
If the unit is very cold or hot, do not turn on its power until it has had a chance to acclimate to
CAUTION
its operating environment.
To prevent electrical shock, connect the unit to a properly grounded power outlet. Do not use a
DANGER
three to two prong adapter. This defeats safety grounding.
Do not operate this unit unless all board covers are securely in place.
DANGER
OPERATOR MANUAL(S)
DANGER
The User Manual(s) should be fully read and understood before operating the LOGIQ e/LOGIQ e
Vet/LOGIQ i/Vivid e and kept near the unit for quick reference.
ACOUSTIC OUTPUT HAZARD
DANGER
Although the ultrasound energy transmitted from the LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e
probe is within FDA limits, avoid unnecessary exposure. Ultrasound energy can produce heat
and mechanical damage
Time for Settlement
40
35
30
25
104
95
86
77
2
0
0
0
0
Chapter 3 System Setup
LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
20
15
10
5
0
68
59
50
41
32
0
0
0
2
4
-5
-10
-15
-20
-25
23
14
5
-4
-13
6
8
10
12
14
-30
-35
-40
-22
-31
-40
16
18
20
