Overview; Purpose Of Chapter 3 - GE LOGIQ e R4 Series Basic Service Manual

GE
Direction 5370626-100, Revision 18
Chapter 3
System Setup
Section 3-1

Overview

3-1-1

Purpose of Chapter 3

This chapter contains information needed to install the unit. Included are references to a procedure that
describes how to receive and unpack the equipment and how to file a damage or loss claim.
How to prepare the facility and unit of the actual installation, and how to check and test the unit, probes,
and external peripherals for electrical safety are included in this procedure. Also included in this section
are guidelines for transporting the unit to a new site.
Table 3-1
Section
3-10
3-11
Contents in Chapter 3
3-1
Overview
3-2
Receiving and Unpacking the Equipment
3-3
Packing the Equipment
3-4
Preparing for Installation
3-5
Completing the Installation
3-6
System Configuration
3-7
Software/Option Configuration
3-8
Connectivity Installation Worksheet
3-9
Loading Base Image Software
Software Version check out
Paperwork
Chapter 3 System Setup
LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Description Page Number
3-1
3-4
3-7
3-8
3-9
3-12
3-30
3-31
3-32
3-33
3-34
3-1
