4-3-7-3 B Mode Softmenu Key
Table 4-4
Step
1
2
3
4
5
6
7
8
9
10
11
12
13
4-12
B Mode Softmenu Key
Task
Adjust Rejection
Activate Colorize
Adjust Edge Enhance
Adjust Edge Enhance/Contour
Activate Gray Map
Adjust Frequency
Adjust Frame Average
Adjust DDP
Adjust Rotation
Adjust Line Density
Adjust Frame Rate
Power output
Dynamic Range
Focus Number and Position
Virtual Convex
Virtual Apex
Section 4-3 - General Procedure
LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Expected Result(s)
Selects a level below which echoes will not be
amplified (an echo must have a certain
minimum amplitude before it will be processed).
Enables gray scale image colorization. To
deactivate, reselect a Gray Map.
Edge Enhance brings out subtle tissue
differences and boundaries by enhancing the
gray scale differences corresponding to the
edges of structures. Adjustments to M Mode's
edge enhancement affects the M Mode only.
Edge Enhance brings out subtle tissue
differences and boundaries by enhancing the
gray scale differences corresponding to the
edges of structures. Adjustments to M Mode's
edge enhancement affects the M Mode only.
Determines how the echo intensity levels
received are presented as shades of gray.
Multi Frequency mode lets you downshift to the
probe's next lower frequency or shift up to a
higher frequency.
Temporal filter that averages frames together.
This has the effect of presenting a smoother,
softer image.
Temporal filter that averages frames together.
This has the effect of presenting a smoother,
softer image.
Rotates the image by selecting the value from
the pop-up menu.
Optimizes B Mode frame rate or spatial
resolution for the best possible image.
Optimizes B Mode frame rate or spatial
resolution for the best possible image.
Optimizes image quality and allows user to
reduce beam intensity. 2% increments between
0-100%. Values greater than 0.1 are displayed.
Dynamic Range controls how echo intensities
are converted to shades of gray, thereby
increasing the adjustable range of contrast.
Increases the number of transmit focal zones or
moves the focal zone(s) so that you can tighten
up the beam for a specific area. A graphic caret
corresponding to the focal zone position(s)
appears on the right edge of the image.
Virtual Convex for linear probe
Virtual Convex for Sector probe
comments
For LOGIQ e, LOGIQ e Vet and
LOGIQ i
For Vivid e
For LOGIQ e, LOGIQ e Vet and
LOGIQ i
For Vivid e
For LOGIQ e, LOGIQ e Vet and
LOGIQ i
For Vivid e
Only for LOGIQ e R5.x.x/R6.x.x/
R7.x.x, LOGIQ e Vet, LOGIQ i R5.x.x,
Vivid e R5.x.x, Vivid e R6.x.x
