4-3-9-2 Color Flow Mode OP Panel Controls
Table 4-7
Step
1
2
Color Flow Mode OP Panel Controls
Task
Press CFM-Mode key
Adjust Gain
Chapter 4 Functional Checks
LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
Expected Result(s)
CFM Mode Starts
Amplifies the overall strength of the echoes
processed in the Color Flow window. Turn the
Gain dial (CFM Mode key) to the left/right to
increase/decrease Gain.
comments
4-17
