Direction 5370626-100, Revision 18
7-7-1-2 Wireless LAN Network
1.) Connect wireless LAN card with system.
2.) Click Start at the left bottom of screen, and select "Network Connections.
3.) In the pop-up window choose Wireless Network Connection. Click it with cursor key, then select
View Available Wireless Networks.
For LOGIQ e R5.x.x/R6.x.x/R7.x.x, Vivid e R5.x.x/R6.x.x,
LOGIQ i R5.x.x, LOGIQ e Vet R6.x.x/R7.x.x
Figure 7-13 Start menu
Figure 7-14 Wireless Network Connection configuration
Chapter 7 Diagnostics/Troubleshooting
LOGIQ e/LOGIQ e Vet/LOGIQ i/Vivid e Basic Service Manual
For LOGIQ e R4.x.x, LOGIQ i R4.x.x, Vivid e R4.x.x
7-17
