3.21 MIDI control

For this you connect, for example, a MIDI key board or another Midi source with
the controller.
This controller can receive MIDI notes and use these for the control and call up the
different functions. There are 2 different Midi reservations selectable:
Midi Synthesizer allocation
Here the individual scenes of the first 15 banks are directly accessible by Midi. In
addition the Chaser and the Blackout function can be steered.
Midi key board reservation
This reservation is optimized, to use the controller in live environments with a 49
keys Midi key board. The 30 banks as well as the 6 Chaser are directly callable as
programs. Not only with the Chaser and the Blackout function, but also the Freeze
function, auto-beat, music clock, Tapsync and the overlays can be controlled.
In both reservations "pitch Wheel" and "modulation Wheel" (= Midi CONTROLLER
type # 1) instructions the functions of the speed and of the Fade time Faders over
Midi can be controlled.
Pitch Wheel:
The pitch wheel steers the function of the speed Faders, the choice of the value of
the auto-beat or the music clock.
Reference:
In the auto-beat the controllable range is limited to max. 10,96s. This simplifies the
handling in live environments, since larger values are mostly not desired and the
resolution of many pitch wheels is not sufficient, in order to enter smaller values
with sufficient accuracy.
Modulation Wheel:
The Modulation Wheel steers the function of the Fade time Fader. Here the Fade
time values of 0s-32s can be entered.

3.21.1 The Midi key board reservation

This reservation is optimized, to use the Scanoperator in live environments with a
49 keys Midi key board. The 30 banks as well as the 6 Chaser are directly callable
