Tools Required But Not Supplied; Table 3-14 Tools Required But Not Supplied - BENDIXKing XVUE TOUCH Installation Manual

Table 3-13 Installation Materials Required but Not Supplied
Description
1/4 inch Braid
32 GB USB drive with Type-C form
factor or
32 GB USB drive and USB-C adapter

3.3.3 Tools Required but Not Supplied

The following tools are required for installation but not supplied:
Part Number or Specification
Commercially Available
Commercially Available
Commercially Available
Commercially Available
KS5549
Commercially Available
Commercially Available
Commercially Available
Commercially Available
Commercially Available
Commercially Available
Commercially Available
D-sub 78 Pin Socket and Pin Connector Tools for the KSD 100 EXP Backshell Assembly Installation Kit
M81969/1-04 Green and White Metal Insert/Removal Tools
AFM8
K42
D-sub 9 Pin Socket and Pin Connector Tools for the KCP 100EXP Control Panel Installation Kit
M81969/1-02 Red and White Metal
AFM8
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
PN or Specification
Commercially
Available
Commercially
Available

Table 3-14 Tools Required But Not Supplied

Description
Screwdriver
Torque Wrench
Milliohm Meter & Multi Meter
Clamp-on In-Circuit Ammeter
Kell-Strom Pro 360 Digital
Inclinometer
Pitot/static tester
NAV/ILS Signal Generator
Aircraft Power Unit
Ring/Terminal Crimper
Environmental Crimper
Maintenance PC
USB to Serial Converter/Adapter
(89000120-002)
Crimp Tool
Crimper Turret Head, Positioner
(89000126-004)
Insert/Removal Tools
Crimp Tool
Quantity Note
As Required
As Required
Notes
Equivalent inclinometer
with accuracy of ± 0.1
degrees
GMT232/ M22520/37-01
Loaded with the CMT
M22520/2-01
M22520/2-09
M22520/2-01
xVue Touch Installation Manual
Page 3-10
