Repair And Return - BENDIXKing XVUE TOUCH Installation Manual

Symptom
KSD OVERTEMP
WARNING TERRAIN TERRAIN
WARING OBSTACLE OBSTACLE
CAUTION TERRAIN TERRAIN
CAUTION OBSTACLE OBSTACLE Caution during flight
ATTITUDE ALIGNING

8.6 Repair and Return

If repair is necessary, the units must be sent to a BendixKing repair facility. There are no field repairable
items inside the xVue Touch LRUs.
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 8-6 Alerts Troubleshooting Chart
Causes
KSD 100EXP Unit Temperature Is
Too High
Warning during flight
Warning during flight
Caution during flight
Attitude is in alignment
Corrective Action
• Turn KSD 100EXP off to allow it
to cool down
• Check for adequate ventilation
• Check airflow around the KSD
100EXP for any blockages
Comply with Warning
Comply with Warning
Comply with Caution
• Comply with Caution
• Let system align
• If system will not complete
alignment use Table 8-4 for
troubleshooting the KG 71EXP
system.
xVue Touch Installation Manual
Page 8-23
