5.2 KCP 100EXP

Input/Output data and power to the KCP 100EXP is transmitted and received through an RS-232
interface, 9-pin male DB-9 connector referenced as J1.

Table 5-3 KCP 100EXP J1 Pin Descriptions (Viewed from LRU)

J1 Pin
1
2
3
4
5
6
7
8
9

5.3 KG 71EXP

5.3.1 KG 71EXP Connector – J71
The electrical interface for the KG 71EXP is provided via the 50 pin D-Sub connector referenced as J71.

Table 5-4 KG 71EXP J71 Pin Descriptions (Viewed from LRU)

J71 Pin
1
2
3
4
5
6
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Description
Ground
RS232_TX_OUT
RS232_RX_IN
Spare
Ground
Spare
Spare
15VDC_PWR_RTN
15VDC_PWR_IN
Description
Power Input
Power Input
Power Input (Spare)
Spare
Attitude Valid
Excitation Wave 26VAC
I/O
GND
Out
In
-
GND
-
-
GND
PWR
I/O
In
In
In
N/A
Out
In
