5.6 KDC 100EXP
The electrical interface for the KDC 100EXP is provided via the 15 pin DB-15 connector.Details about the
connector interface are shown in Table 5-9.
Table 5-9 KDC 100EXP Pin Descriptions (Viewed from LRU)
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SHIELD WIRING MUST REMAIN IN BACKSHELL (CONNECT TO GROUND LUG INSIDE
BACKSHELL).
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Description
Magnetometer 429 RX HI
Magnetometer 429 RX LO
Ground
Magnetometer CAN LO Bi-Direction
Magnetometer CAN HI Bi-Direction
Ground
Maintenance RS232 Tx
Maintenance RS232 Rx
Maintenance RS232 Gnd
Not Used
Not Used
Not Used
Not Used
Power-In-Rtn
Power-In
NOTE
Figure 5-3 KDC 100EXP Backshell
I/O
In
In
NC
Out
Out
NA
Out
In
Gnd
NC
NC
NC
NC
In
In
