SHIELD WIRING MUST REMAIN IN BACKSHELL (CONNECT TO GROUND LUG INSIDE
BACKSHELL).

5.5 MD32

The electrical interface for the MD32 is provided via the 9 pin DB-9 connector Table 5-8.

Table 5-8 MD32 DB-9 Pin Descriptions (Viewed from LRU)

Pin
1
2
3
4
5
6
7
8
9
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
NOTE

Figure 5-2 KMG 7010 Backshell

Description
Ground
Not Used
Reserved
Reserved
Power
ARINC B
ARINC A
Not Used
Not Used
I/O
GRN
-
-
-
-
Out
Out
-
-
xVue Touch Installation Manual
Page 5-10
