BENDIXKing XVUE TOUCH Installation Manual page 109

J2 Pin Description
49 GS_+_DOWN_IN
50 IFD1_ETH_RX_P
51 IFD1_ETH_RX_N
52 IFD2_ETH_RX_P
53 IFD2_ETH_RX_N
54 Spare GND
55 Spare GND
56 Spare GND
57 Spare GND
58 Spare GND
59 KSD100_CTRL_PANEL_PWR_RTN
60 NAV_DEV_+_RT_IN
61 NAV_DEV_+_LT_IN
62 NAV_FLAG_+_IN
63 NAV_FLAG_-_IN
64 APM_DATA_MISO
65 APM_DATA_MOSI
66 APM_CLK
67 APM_DATA_CS_N
68 APM_WP_N
69 APM_PWR_3P3VDC
70 APM_PWR_RTN
71 LIGHTNING_RS232_RX
72 EIS_RS232_TX
73 EIS_RS232_RX
74 KSD100_MAINT_RS232_TX
75 KSD100_MAINT_RS232_RX
76 KSD100_CTRL_PANEL_RS232_TX
77 KSD100_CTRL_PANEL_RS232_RX
78 KSD100_CTRL_PANEL_PWR_15VDC
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
I/O Initial Certification
In Included
In Reserved
In Reserved
In Reserved
In Reserved
GND Reserved
GND Reserved
GND Reserved
GND Reserved
GND Reserved
GND Included
In Reserved
In Reserved
In Reserved
In Reserved
In Included
Out Included
Out Included
Out Included
Out Included
PWR Included
GND Included
In Reserved
Out Reserved
In Reserved
Out Included
In Included
Out Included
In Included
PWR Included
xVue Touch Installation Manual
Page 5-5
