Table 3-3 Installation Kit, Backshell Assembly – KSD 100EXP, PN 89000120-002
Part Number
MS51959-17
7024206-10
MS51957-13
MS35335-57
Table 3-4 Installation Kit, Configuration Module & Connectors – KSD 100EXP, PN 89000120-003
Part Number
89400020-064
53504890-1
53504891-2
53501676-2
53504891-1

Table 3-5 Installation Kit, Mounting Hardware and Grip - KSD 100EXP, PN 89000120-007

Part Number
89500020-024
MS51957-1B
NAS1352-08-10

Table 3-6 KCP 100EXP Control Panel Installation Kit for Portrait Mounting, PN 89000126-004

Part Number
53504988-1
53504891-3
D9000GE0/AA

Table 3-7 KCP 100EXP Control Panel Installation Kit for Landscape Mounting, PN 89000126-005

Part Number
89500026-010
MS51957-33
089-02353-0001
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Description
Phillips Flat Head Countersunk Screws
Captive Socket Head Cap Screws
Phillips Pan Head Screws
Lock Washers
Description
Circuit Card Assembly, Programmed, Configuration
Module
78-pin D-Sub Male Connector
Connector Contact Crimp Pin Size 22
78-pin D-Sub Female Connector
Connector Contact Crimp Socket Size 22
Description
KSD 100EXP Grip
#2-56 X 1/8 inch Pan Head Screws
#8-32 X 5/8 inch Socket Head Cap Screws
Description
Connector, SD Series, 9 Pin
Contacts – Size 20
Connector Backshell
Description
KCP 100 Center Stack Adapter
#6-32 X 7/8 inch Pan Head Screw
#6-32 Self Locking Clip Nut
Qty UM
4 EA
4 EA
22 EA
22 EA
Qty UM
1 EA
1 EA
78 EA
1 EA
78 EA
Qty UM
1 EA
8 EA
4 EA
Qty UM
1 EA
9 EA
REF REF
Qty UM
1 EA
4 EA
4 EA
xVue Touch Installation Manual
Page 3-6
