Table 2-15 KDC 100EXP Environmental Qualification Form (EQF)

DO-160G
Conditions
Section
4.0 Temperature
8.0 Vibration

Table 2-16 KTP 73 Environmental Qualification Form (EQF)

DO-160G
Conditions
Section
4.0 Temperature and Altitude
5.0 Temperature Variation
6.0 Humidity
7.0 Operational Shocks and Crash Safety
8.0 Vibration
9.0 Explosive Atmosphere
10.0 Waterproofness
11.0 Fluids Susceptibility
12.0 Sand and Dust
13.0 Fungus Resistance
14.0 Salt Fog
15.0 Magnetic Effect
16.0 Power Input
17.0 Voltage Spike
18.0 Audio-Frequency Conducted
Susceptibility
19.0 Induced Signal Susceptibility
20.0 Radio Frequency Susceptibility
(Radiated and Conducted)
21.0 Emission of Radio Frequency Energy
22.0 Lightning Induced Transient Susceptibility
23.0 Lightning Direct Effects
24.0 Icing
25.0 Electrostatic Discharge
26.0 Flammability
89000109-002
Rev 2
