Table 2-10 KSD 100EXP Environmental Qualification Form (EQF)
DO-160G
Conditions
Section
Notes:
1. Duplicate testing not required per DO-160G Section 16.6.1.2's Note.
2. No test performed since the Line Replaceable Unit (LRU) has a metallic enclosure.
3. Analysis - Enclosure is constructed of metal on five sides
• Test – Polycarbonate display with 12 second vertical burn
• Test – Grip (Santoprene) with horizontal burn
• Test – Bezel Seal - Neoprene Cord with horizontal burn
4. Conducted Susceptibility (CS) testing was performed using DO-160E Cat A per FAA Policy PS-ACE-23-10.
5. Radiated Susceptibility (RS) testing was performed using the following levels per FAA Policy PS-ACE-23-10:
Frequency
100 - 200 MHz
200 - 400 MHz
400 - 700 MHz
700 MHz – 1 GHz
1 - 2 GHz
2 - 4 GHz
4 - 6 GHz
6 - 8 GHz
8 - 12 GHz
12 - 18 GHz
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Category
DO-160G
Sect 20 Category
Cat G
Cat G
Cat F
Cat F
Cat D
Cat D
Cat D
Cat D
Cat D
Cat D
Notes
V/m
SW/CW PM
100 -
100 -
25 350
50 350
50 500
50 750
50 750
50 250
75 750
50 500
