For new installations utilize the connectors, circuit card assembly, etc. included in the xVue Touch System
Installation Kits or in Installation Materials Required but Not Supplied and referenced in Table 4-2:
Description
KSD 100EXP Backshell Assembly Installation Kit
KSD 100EXP Configuration Module and Connector
Installation Kit
KCP 100EXP Control Panel Installation Kit
KG 71EXP ADAHRS Installation Kit
KMG 7010 Magnetometer Installation Kit
MD32 Connector Kit
KDC 100EXP Installation Kit
Overbraid
Wire routing, bend radius, and harness preparation should be in accordance with AC 43.13-1B Chapter 11
Sections 8 through 11. It is the installers' responsibility to ensure the airworthiness of any additional
equipment interfaced to the xVue Touch System.

4.11 Weight and Balance Analysis

A revised weight and balance computation is required after the installation of the xVue Touch System.
The weight and balance report must be carried out in accordance with the guidance in AC 43.13-1B,
Chapter 10, Section 2, Paragraphs 10-16 through 10-23, pages 10-12 through 10-23.
Prepare a weight and balance report for the airplane records and verify that the airplane does not exceed
the authorized weight and Center of Gravity (CG) limits as shown in the Type Certificate Data Sheet
(TCDS) and airplane specification(s).
The various xVue Touch System components and associated nominal weights are listed in Table 4-3
below. Note: The connector and backshell weights are not included.
Table 4-3 xVue Touch System Component Weights & Centers of Gravity
xVue Touch System Components
KSD 100EXP Primary Flight Display
KSD 100EXP Installation Kit
(Mounting Hardware and Grip)
KG 71EXP ADAHRS
KCP 100EXP Control Panel (Portrait)
KCP 100EXP Control Panel
(Landscape)
KCP 100EXP Installation Kit (Center
Stack - Landscape)
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft

Table 4-2 Wiring Harness Equipment

Installation Kit PN
89000120-002
89000120-003
89000126-004
89000123-007
050-03643-0000
9019092-1
89000138-002
N/A
Part Number Weight (lb) Weight (kg)
89000120-001-[ ]
89000120-007
89000123-001-[ ]
89000126-001-[ ]
89000126-003-[ ]
89000026-005
Additional Information
Table 3-3
Table 3-4
Table 3-6
Table 3-8
Table 3-9
Table 3-9
Table 3-11
Table 3-13
6.9 3.13 See Figure A-1
0.75 0.34
2.0 0.91 SeeFigure A-6
0.93 0.42 See Figure A-3
0.1 0.05
xVue Touch Installation Manual
C of G
N/A
N/A
Page 4-21
