Symptom
DATABASE LOAD FAIL
NAVIGATION
OBSTACLE
CARTOGRAPHIC
TERRAIN
CHARTS
IFR LOW ALTITUDE
IFR HIGH ALTITUDE
VFR SECTIONAL
DATABASE EXPIRED
DATABASE FUTURE CYCLE
UAT NO COMMUNICATION
UAT POSITION FAIL
SET BARO
AHRS IN-MOTION ALIGMENT
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 8-6 Alerts Troubleshooting Chart
Causes
Database CRC Failed During
Database Loading
Database Has Failed to Load
Database Tiles Failed to Load
During Run Time
Database Tiles Corrupted During
Run Time
Database(s) has expired
Newer version of a database has
loaded before the effectivity date
No Data Received on the Bus from
the UAT Receiver
The UAT's GPS position is invalid
BARO is not set
AHRS is in alignment during flight
Corrective Action
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• Reload failed database using a
different USB drive
• If fault persists, replace KSD
100EXP
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• Reload failed database using a
different USB drive
• If fault persists, replace KSD
100EXP
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• If fault persists, replace KSD
100EXP
• Reload failed database
• Re-download failed database
source content to USB drive and
reload failed database
• If fault persists, replace KSD
100EXP
Download the latest database(s)
Verify database effectivity date
See "UAT FAIL" troubleshooting
procedure in this table.
If the UAT's GPS is used for ADS-B
Out, ADSB Out is no longer
provided
Set BARO to current setting
Fly straight and level If possible
until system is done with
alignment.
xVue Touch Installation Manual
Page 8-21
