Unpacking And Inspection - BENDIXKing XVUE TOUCH Installation Manual

Part Number or Specification
9502-10-0-0 K694
D-sub 50 Socket and Pin Connector Tools for the KG 71EXP ADAHRS Installation Kit
M81969/1-04 RED and White Metal
AMF8
K13-1
D-sub 9 Socket Connector Tools for the KMG 7010 Magnetometer Installation Kit
M81969/1-02 Red and White Metal
AFM8
9502-10-0-0 K694
D-sub 9 Socket Connector Tools for the MD32 Magnetometer Connector Kit
M81969/1-02 Red and White Metal
AFM8
9502-10-0-0 K694
D-sub 9 Socket Connector Tools for the KDC 100EXP Installation Kit
M81969/1-02 Red and White Metal
AFM8
9502-10-0-0 K694

3.4 Unpacking and Inspection

Exercise caution when unpacking the xVue Touch System equipment. Confirm receipt of all installation
components refer to, Table 3-2, for the appropriate part lists. Inspect all components for any damage,
contact BendixKing Customer Support if any parts are missing or damaged. The shipping container and all
packing materials must be retained in the event that storage or reshipment of the equipment is
necessary. If a damage claim is needed, the shipping container and all packing materials will be used to
substantiate your claim. The claim must be filed as soon as possible.
THE KSD 100EXP, KCP 100EXP, KG 71EXP AND KMG 7010/MD32 EXTERNAL CONNECTORS
SHOULD BE PROTECTED WITH AN ESD COVER WHEN NOT INSTALLED ON THE AIRPLANE.
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Table 3-14 Tools Required But Not Supplied
Description
Crimper Turret Head, Positioner
(89000123-007)
Insert/Removal Tools
Crimp Tool
Crimper Turret Head, Positioner
(050-03643-0000)
Insert/Removal Tools
Crimp Tool
Crimper Turret Head, Positioner
(9019092-1)
Insert/Removal Tools
Crimp Tool
Crimper Turret Head, Positioner
(89000138-002)
Insert/Removal Tools
Crimp Tool
Crimper Turret Head, Positioner
NOTE
Notes
Positronic
M22520/2-01
M22520/2-08
M22520/2-01
Positronic
M22520/2-01
Positronic
M22520/2-01
Positronic
xVue Touch Installation Manual
Page 3-11
