Table 2-4 Kg 71Exp Adahrs Specifications; Table 2-5 Kg 71Exp Adahrs Performance Characteristics - BENDIXKing XVUE TOUCH Installation Manual

Characteristic
Dimensions
Weight
Current Draw
Operating Voltage
Circuit Breaker
Cooling
Connectors

Table 2-5 KG 71EXP ADAHRS Performance Characteristics

Characteristic
Time to Initialize
Airspeed Range
Altitude Range
Vertical Speed Range
Baro-Correction Range
Roll/Pitch Accuracy
Roll/Pitch Range
Heading Accuracy
Heading Range
Slip/Skid Accuracy
Slip/Skid Range
Turn Rate Output Accuracy
Turn Rate Output Range
Max Pitch/Roll/Yaw Rate
Max Sustained G
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft

Table 2-4 KG 71EXP ADAHRS Specifications

Specification
8.65 x 5.1 x 1.4 inches (219.72 x 129.43 x 35.56 mm)
2.2 lbs. (1.0 kgs.) Max. Weight
Typical (28VDC): 0.2 AMP
Typical (14VDC): 0.4 AMP
9.0 to 32.2 VDC
(9VDC on battery backup, 11VDC for power-up, and 32.2VDC max)
2 AMP for 28 VDC, 3 AMP for 14 VDC systems
Convection cooled (does not required forced air cooling within the unit
operational temperature range, refer to Section 3.6.7.3 for cooling
considerations)
Male 50-pin D-sub
Female 9-pin D-sub (Maintenance port)
Specification
Up to 3 min
20 to 350 kts
-1,000 to 35,000 ft
-20,000 to 20,000 ft/min
22 to 31.50 InHg
DO 334 Category A4
Roll: ± 180 Degrees
Pitch: ± 90 Degrees
DO 334 Category H4
±180 Degrees
DO 334 Category T3
DO 334 Category T3, Max. range ±8.5 Degrees
DO 334 Category T3
±128 Degrees/Second
± 245 deg/sec
± 4g
