1 INTRODUCTION

1.1 How to Use This Manual

1.1.1 General

(1) This publication gives installation and maintenance instructions for the equipment shown on the
Title page.
(2) Standard maintenance procedures that technicians must know are not given in this manual.
(3) Warnings, cautions, and notes in this manual give the data that follows:
The WARNING symbol indicates a condition or tells personnel what part of an operation or
maintenance procedure, which if not obeyed, can cause injury or death.
The CAUTION symbol indicates a condition or tells personnel what part of an operation or
maintenance procedure, which if not obeyed, can cause damage to the equipment.
The NOTE symbol indicates data, not commands. The NOTE helps personnel when they do
the related instruction.
(4) Warnings and cautions precede the applicable paragraph or step. Notes follow the applicable
paragraph or step.

1.1.2 Observance of Manual Instructions

(1) Make sure that you carefully obey all safety, quality, operation, and shop procedures for the unit.
(2) All personnel who operate equipment and do maintenance specified in this manual must know
and obey the safety precautions.

1.1.3 Symbols

(1) The symbols and special characters are in alignment with IEEE Publication 260 and IEC Publication
27. Special characters in text are spelled out.
(2) The signal mnemonics, unit control designators, and test designators are shown in capital letters.
(3) The signal names followed by an "*" show an active low signal.
(4) The symbols in Figure 1-1 show ESDS and moisture sensitive devices.

1.1.4 Units of Measure

Measurements, weights, temperatures, dimensions, and other values are expressed in the USMS
followed by the appropriate SI metric units in parentheses. Some standard tools or parts such as drills,
taps, bolts, nuts, etc. do not have an equivalent.

1.1.5 Electrostatic Discharge

Handle the items susceptible to electrostatic discharge in accordance with MIL-HDBK-263. Refer to MIL-
STD-1686 for definition of the standards and conditions.
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft

Figure 1-1 Symbols

xVue Touch Installation Manual
Page 1-1
