Characteristic
Dimensions
Weight
Temperature
Altitude
Operating Voltage
Current Draw
(at 27.5 VDC)
Circuit Breaker
Signal Inputs/Outputs
Cooling
Connector
Certifications

Table 2-9 KTP 73 Outside Air Temperature Probe Specifications

Characteristic
Dimensions
Weight
Current Draw
Operating Voltage
Circuit Breaker
Cooling
Connectors
Certifications
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft

Table 2-8 KDC 100EXP Data Converter Specifications

Specification
3.70 x 5.83 x 1.33 inches (93.98 x 148.08 x 37.78 mm)
0.99 lbs (0.45 kgs) Max. Weight
-55 °C to +70°C
55,000 ft.
14 to 28 VDC
80 mA Nominal, 25°C, after 2 minute warmup
200 mA Nominal, -55°C, after 2 minute warmup
700 mA Maximum, -55°C
1 AMP for 28 VDC, 2 AMP for 14 VDC systems
Serial CAN Bus
Convection cooled. No external cooling required.
Male 15-pin
TSO-C6d/ETSO-C6d (partial)
Specification
1.65 x 1.75 x 1.00 inches (41.91 x 44.45 x 25.4 mm)
0.17 lbs (0.07 kgs) Max. Weight
NA, not connected to the airplane power bus.
Connected to the ADAHRS, no interface to the airplane power.
NA
Mounted outside the airplane. No cooling required.
5 ft. 3-conductor shielded wire lead, spliced into AC wiring harness.
TSO-C106 (Incomplete)
xVue Touch Installation Manual
Page 2-8
