5.3.3 KG 71EXP Maintenance Port

The maintenance port pinout uses a standard PC COMM Port connector, female D-Sub. Details about the
maintenance port, J2, interface are shown in Table 5-6 KG 71EXP Maintenance Port Pin Descriptions
(Viewed from LRU).

Table 5-6 KG 71EXP Maintenance Port Pin Descriptions (Viewed from LRU)

J2 Pin
1
2
3
4
5
6
7
8
9

5.4 KMG 7010

The electrical interface for the KMG 7010 is provided via the 9 pin DB-9 connector referenced as J7010.
Details about the J7010 connector interface are shown in Table 5-7

Table 5-7 KMG 7010 DB-9 Pin Descriptions (Viewed from LRU)

J7010 Pin
1
2
3
4
5
6
7
8
9
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Description
Spare
Serial Channel 0 RX data
Serial Channel 0 TX data
Spare
Ground
Spare
Serial Channel 0 Request to Send
Serial Channel 0 Clear to Send
Spare
Description
AC Power
Spare
CAN Bus Hi
CAN Bus Hi
CAN Bus Lo
Power Ground
Chassis Ground
Spare
CAN Bus Lo
I/O
-
In
Out
-
GND
-
Out
In
-
I/O
In
-
In/Out
In/Out
In/Out
GND
GNS
-
In/Out
