Table 3-8 KG 71EXP Installation Kit PN 89000123-007

Description
50-pin D-Sub Female Connector
Contacts
Connector Backshell, D-Sub, w/Jackscrews

Table 3-9 KMG 7010 Installation Kit PN 050-03643-0000

Description
Connector, D-Sub, Receptacle, Hsg, Brass Shell, 9-
Pos
KMG 7010 Installation Drawing
Instruction For Harness Assembly Parts
Crimp Terminal 4S
Socket Crimp 20G
Connector, D-Sub, Hood, EMI/RFI, Metal,
Jackscrews, 9-Pos
TSO Label, KMG 7010
Nut Lock 10-32
Screw Flat Head Phillips 10-32 X 5/8
Screw Flat Head Phillips 3-48 X 3/16
Screw Flat Head Phillips 3-48 X 5/16
Screw Flat Head Phillips 3-48 X 1/2
Passivated SS Non-Magnetic Flat Std. #10 Washer

Table 3-10 MD32 Connector Kit PN 9019092-1

Description
Connector, D-Sub, Receptacle, Hsg, Brass Shell, 9-
Pos

Table 3-11 KDC 100EXP Installation Kit PN 89000138-002

Description
Connector, D-Sub
Qty UM
1 EA
50 EA
1 EA
Qty UM
1 EA
REF REF
REF REF
1 EA
9 EA
1 EA
1 EA
4 EA
4 EA
1 EA
4 EA
2 EA
4 EA
Qty UM
1 EA
Qty UM
1 EA
