2.3.6 KTP 73 OAT Probe

The KTP 73 OAT probe measures air temperature and provides the data to the KG 71EXP. Total air
temperature is sensed by the independent probe. The temperature probe is a platinum 500 Ohm thermal
sensor. Total air temperature is used to calculate the OAT and is required for the true airspeed
calculation.

2.4 Technical Specifications

Table 2-2 KSD 100EXP Primary Flight Display Specifications

Characteristic
Dimensions
Mounting Information
Weight
Current Draw
Operating Voltage
Circuit Breaker
Cooling
Connectors
Viewing Angle Envelope
Characteristic
Dimensions
Mounting Information
Weight
Current Draw
Operating Voltage
Circuit Breaker
Cooling
Connectors
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
Specification
6.897 x 10.45 x 4.08 inches (175.18 x 265.43 x 103.63 mm)
Front mount
7.59 lbs. (3.44 kgs.) Max. Weight
Typical (28VDC): 1.33 AMP
Typical (14VDC): 2.66 AMP
9.0 to 32.2 VDC
(9VDC on battery backup, 11VDC for power-up, and 32.2VDC max)
2 AMP for 28 VDC, 3 AMP for 14 VDC systems
Convection cooled (does not required forced air cooling within the unit
operational temperature range, refer to Section 3.6.5.2 for cooling
considerations)
2 D-sub connectors (Female 78-pin and Male 78-pin)
80 degree max viewing angle from all directions

Table 2-3 KCP 100EXP Control Panel Specifications

Specification
1.48 x 6.25 x 3.67 inches (37.6 x 158.8 x 93.2 mm)
Front mount
1.02 lbs. (0.46 kgs.) Max. Weight
The KCP 100EXP is powered from KSD 100EXP and the KCP 100EXP
current draw is included with the KSD 100EXP values shown in Table 2-2.
Operating Voltage is provided by the KSD 100EXP.
The KCP 100EXP is powered from KSD 100EXP. The circuit breaker
defined under the KSD 100EXP Primary Flight Display Specifications is
sufficient.
Convection cooled (does not required forced air cooling within the unit
operational temperature range)
Male 9-pin D-Sub
