BENDIXKing XVUE TOUCH Installation Manual page 58

Table 3-13 Installation Materials Required but Not Supplied
Description
Straight AN816-4D to 1/8 inch, NPT
Male or
Elbow AN822-4D to 1/8 inch, NPT
Male
Straight AN816-4D to 1/8 inch, NPT
Male or
Elbow AN822-4D to 1/8 inch, NPT
Male
Pitot/Static Hose (match to
individual aircraft's needs)
Nutplates #8-32
Nutplates #4-40
Rivets
#10-32 Rivet nuts
Stainless Steel Mounting Screws #6-
32
Washer head screws
Washers
Tie Wraps or Lacing Cord
Non-pressure vessel mounting
sealant, DOW Corning 3145
Pressure vessel mounting sealant, PS
870B-1/2
Thread-locking compound
Bonderite M-CR 1132 Aero -
Conversion coating
Thread-seal tape (PTFE)
Self-Fusing Silicon Tape, 3M 83010
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
PN or Specification Quantity
Commercially
Available
Commercially
Available
Commercially
Available
MS21061L08 or
MS21071L08
MS21069L04 or
MS21071L04
MS20426AD3-X
NAS1329A3KXX
MS35206-230
AN525-10R
AN960-10
Commercially As Required
Available
MIL-A-46146 As Required
MIL-PRF-81733D As Required
Commercially As Required
Available
1445846 As Required
Commercially As Required
Available
Commercially As Required
Available
Note
1 Fitting (Static)
1 Fitting (Pitot)
A/R A combination of different
materials can be used for
the pitot /static lines
4 Orientation is optional as
long as minimum edge
distance is maintained
4 Orientation is optional as
long as minimum edge
distance is maintained
16 X = size
4 XX = size
4
4
4
xVue Touch Installation Manual
Page 3-9
