6.2.4 Autopilot Configuration Setup

THE PROCESS FOR CONFIGURING THE AUTOPILOT AND KSD 100EXP INTERFACE IS
DESCRIBED IN SECTION 7.2.10.1 AUTOPILOT & KSD 100EXP INTERFACE.
The Autopilot button allows the technician to configure the following parameters, as shown in Figure 6-
36:
(1) Autopilot LRU
(2) Sync FD Offset
(3) Sync FD Gain
FLIGHT DIRECTOR (FD) FUNCTION IS NOT AUTHORIZED.
(4) GPSS K Factor
89000109-002
Rev 2
© Honeywell International Inc. Do not copy without express permission of Honeywell.
For Use in Non-Certified Aircraft
NOTE
NOTE

Figure 6-36 Autopilot Sub-Menu
